MvR Airplane Type · MvR AT002
Albatros D.III
A Fighter by Albatros Flugzeugwerke.
Images
Related Images
Victory 18
»Le petit rouge«
Victory 25
Victory 28
Victory 32
First Dublette
Victory 33
Victory 34
Victory 35
Victory 36
Victory 37
Victory 38
Victory 39
Victory 40
Victory 41
About victory 41
Victory 42
Victory 43
My most successful day so far
Victory 45
Victory 46
Victory 47
Victory 48
Victory 49
Victory 50
The newspaper
Victory 51
Victory 52
Victory 53
Victory 17
MvR visits Jasta 12 in Epinoy
Albatros D.III
Albatros D.III
Albatros D.III
Albatros D.III
Description
As soon as the D.II was in production, its designer turned to a more advanced version intended to offer considerably improved manoeuvrability. The result was the D.III that retained the fuselage and empennage of the D.II but added a version of the D.III engine with a higher compression ratio for slightly more power, and adopted a new wing cellule without stagger. The wings comprised a longer-span upper wing with raked tips and a narrow-chord lower wing in a sesquiplane arrangement with V-layout interplane struts. At the same time the radiator was shifted from the centre section to the starboard wing so that a bullet puncture would not result in the pilot being scalded. The D.III entered service in the spring of 1917, and was produced in large numbers to become the decisive fighter over the Western Front between that time and the autumn of the same year. (source: The International Encyclopedia of Aircraft, Oriole Publishing, 1991)
